Product Description
Ball Plunger and Parting Lock
Technical Specification of the ball plunger:
Type No. | M X Pitch | d | S | L | max load | U'price |
| GBP-4 | 4X0.7 | 2.5 | 1.0 | 9 | 0.3 | 1.0 | 8 |
| GBP-5 | 5X0.8 | 3.0 | 1.0 | 12 | 0.5 | 1.5 | 8 |
| GBP-6 | 6X1.0 | 3.5 | 1.2 | 14 | 0.7 | 2.0 | 8 |
| GBP-8 | 8X1.25 | 5.0 | 1.8 | 16 | 0.9 | 2.5 | 8 |
| GBP-10 | 10X1.5 | 6.0 | 2 | 19 | 1.0 | 3.0 | 8 |
| GBP-12 | 12X1.75 | 8.0 | 3 | 22 | 1.6 | 5.0 | 9 |
| GBP-16 | 16X2.0 | 10.0 | 4 | 25 | 2.5 | 8.0 | 23 |
| GBP-4, 5 GBP-6, 8, 10, 12, 16v |
Type No. | (inch) | d | S | L | max load | U'price |
| GBPJ-2½ | 5/16" | 5 | 2 | 17 | 1.3 | 2.6 | 8 |
| GBPJ-3 | 3/8" | 6 | 2 | 17 | 1.0 | 3.0 | 8 |
| GBPJ-4 | 1/2" | 8 | 3 | 17 | 1.6 | 5.0 | 8 |
Feature of the parting locks:
- Use sloping screw to adjust mold plate and parting locks, then turn 90 degrees. Parting locks can be closed up to 50,000 times.
- Easy to assemble and disassemble, and cost efficient.
- Can also be installed into small, medium size, and 2-sectional injecting metal pipes, or can be installed on sliding bases.
- Mold weight <100kg, using 4 pcs of 12Ø, Mold weight < 500kg, using 4 pcs of 16Ø, Mold weight <1,000kg using 4 pcs of 20Ø, Mold weight >1,000kg, using at least 6 pcs
- Insert parting Locks into die mold about 3cm, then using H 7 reamer 10 process mold hole within +0. 1mm range.
- Process mold surface to the shape of letter R. If processing to the chamfering of letter C, it will shorten its life cycle.
- Do not add an oil on parting locks, doing so will reduce the friction. Colour : white. Yellow. Orange
